USAGE：3-Ply-Shuttering-Panel

DESCRIPTION：

Length: (mm) 970 /1000 /1500 /1970 /00 /2500 /3000

Width: (mm) 500

Thickness: (mm) 21, 27

Tolerance on length / width:

(mm) +/-3

(mm) +/-0.5

Number of plies: (plies) 3

Surface: Hot pressed melamine resin

Processing of edges: By waterproof paint

Wood basis: Chinese Fir

Formaldehyde emission class: E2

Glue: WBP

Moisture content: (%) 8-10

TECHENICAL DATA：

Density: (g/cm3) 0.42-0.46

Thickness Inflation Ratio (72 hours' normal water immerse): (%) less than 5

Average bonding strength: (MPa) more than 0.7

Wear Value: (g/100r) more than 0.1

Compression Strength: (KJ/m²)

Longitudinal: More than 23.2

Lateral: More than 13.8

Static bending strength: (MPa)

Longitudinal: More than 26

Lateral: More than 8.9

Modulus of Elasticity: (MPa)

Longitudinal: More than 5500

Lateral: More than 590
